| General | |
| Measurment variables | Resistivity, IP and SP |
| Operating time | 30 data points/second |
| Measurement range | From -10V to +10V |
| SP compensation | Automatic cancellation |
| Resistivity cycle times | From 0.1S to 10S |
| Automatic multi-electrodes | Yes |
| Data samping rate | 100KHZ |
| Data storage | Unlimited |
| Data transmission | USB |
| Power supply | External 12V battery |
| Operating temperature | -20 to +70 oC |
| Operating Humidity | 98% RH |
| Weight | 5.3 kg |
| Dimension | 339 x 295 x 152 mm |
| Built-in GPS | Optional |
| Transmitter | |
| Power | 250W |
| Current | Up to 3A |
| Accuracy | Better than 0.2% |
| Voltage option 1 | 50/120/350V (100/240/700Vp-p) |
| Voltage Option 2 | 100/250/600V (200/500/1200 Vp-p) |
| Receiver | |
| Electrodes | 64 |
| Channels | 61 |
| Accuracy | Within 0.1% |
| Input impedance | > 107 Ohm.m |
| Input voltage protection | 1000V |
| AD resolution | 24 bits |
| Noise suppresion | Better than 100 dB, automatically suppresses powerline noise |
